div rotate test

DBILITY 2021. 5. 18. 16:07
반응형

https://m.blog.naver.com/PostView.naver?blogId=wyepark&logNo=220517029219&proxyReferer=https:%2F%2Fwww.google.com%2F



디그리(degree) 와 라디안(radian)

각도를 나타내는 단위에는 도(degree, 디그리) 와 라디안(radian)이 있습니다. 디그리(degree) 는 원 한바...

blog.naver.com

atan2는 두 점 사이의 상대좌표(x, y)의 절대각을 -π ~ π의 라디안 값으로 반환한다.

<!doctype html>
<html lang="ko">
<head>
    <meta charset="UTF-8">
    <meta name="viewport"
          content="width=device-width, user-scalable=no, initial-scale=1.0, maximum-scale=1.0, minimum-scale=1.0">
    <meta http-equiv="X-UA-Compatible" content="ie=edge">
    <title>Document</title>
    <style>
        html, body {
            margin: 0;
            padding: 0;
            height: 100%;
            overflow: hidden;
        }

        .container {
            position: absolute;
            margin: 0;
            width: 100%;
            min-height: 100%;
            box-shadow: 0 0 0 1px #000 inset;
            padding: 0;
        }

        .layer {
            position: absolute;
            width: 200px;
            height: 200px;
            text-align: center;
            padding: 0;
            border: 1px dotted black;
            vertical-align: middle;
            left: calc(50% - 100px);
            top: calc(50% - 100px);
        }

        .ui-rotate-handle {
            width: 20px;
            height: 20px;
            background-color: #ffffff;
            border: 0px solid #000000;
            position: absolute;
        }

        .ui-rotate-s {
            bottom: -40px;
            left: calc(50% - 10px);
            cursor: grab;
            background-image: url("./image/arrow-repeat.svg");
            background-repeat: repeat;
            background-size: 100%;
        }

        img {
            max-width: 100%;
            max-height: 100%;
        }
    </style>
</head>
<body>
<div class="container">
    <div class="layer">
        <img src="https://dummyimage.com/200x200/fff/000.png&text=Rotatable!" alt="">
    </div>
</div>
<script>

    window.addEventListener('load', e => {
        let layers = document.getElementsByClassName('layer');
        let container = document.getElementsByClassName('container')[0];
        let rotater = document.createElement("div");
        rotater.classList.add("ui-rotate-handle", "ui-rotate-s");
        rotater.id = "rotater";

        layers[0].addEventListener('mousedown', e => {
            e.preventDefault();
            e.stopPropagation();
            layers[0].appendChild(rotater);
        });

        rotater.addEventListener('mousedown', e => {
            let cx = layers[0].offsetLeft + (layers[0].offsetWidth / 2); //회전대상 원점X
            let cy = layers[0].offsetTop + (layers[0].offsetHeight / 2); //회전대상 원점Y
            e.preventDefault();
            container.onmousemove = e => {
                e.preventDefault();
                if (layers[0] != null) {
                    //atan2는 두 점 사이의 상대좌표(x, y)의 절대각을 -π ~ π의 라디안 값으로 반환한다.
                    let rad = Math.atan2(e.pageY - cy, e.pageX - cx);
                    let deg = Math.round(rad * 180 / Math.PI) - 90; // radian to degree, -90 = rotater는 시작점이 6시방향으로 90 회전상태임
                    layers[0].style.transform = 'rotate(' + deg + 'deg)'; // 대상 회전
                    rotater.style.transform = 'rotate(' + deg + 'deg)';  // 로테이터 회전
                }
            }
        });

        rotater.addEventListener('mouseup', e => {
            rotater.onmousemove = null;
            container.onmousemove = null;
            document.onmousemove = null;
        });

        document.addEventListener('mouseup', e => {
            rotater.onmousemove = null;
            container.onmousemove = null;
            document.onmousemove = null;
        });

        container.addEventListener('mousedown', e => {
            e.preventDefault();
            e.stopPropagation();
            if (layers[0].contains(rotater)) {
                layers[0].removeChild(rotater);
            }
        });
    });


</script>
</body>
</html>
